Stack Mounted Lithium Battery
Brand: Lersion
Product origin: China
Delivery time: 2-15 days
Supply capacity: 5000
Movable stack mounted lithium battery
Grade A Lithium Battery
Long cycle life >6000 cycles
High Efficiency & Fast Charging
Intelligent Battery Management
Compatible with Various Inverters
Smart String Energy Storage System
Strong Expansibility Support 16 modules in parallel | Meticulous Care Each module can be independently managed and operated to ensure the safety of the system | Easy Management Pulley bottom, manual switch, and visual supervision interface |
Stronger Compatibility Cover all mainstream protocols and match most mainstream inverters ]C discharge | Long Life 4 times long static and 8 consistency screening make the battery more durable | Safety & reliability Nano-coating and self-healing technolog y construct the LPF channel to add a firewal to the battery |
FLCD16-10048
Technical Specification | FLCD16-10048 |
| Battery Module Model | |
| Battery Module Specification | 51.2V 100AH(100A) |
| Battery Module Energy | 5KWH |
| Battery Module Maximum Output Power | 4.2KW |
| Battery Module Peak Output Power | 5KW 10S |
| Battery Module Rated Voltage(DC) | 51.2V |
| Battery Module BMS Allowable Load Current | 100A |
| Battery Module DC Voltage Range | 44.8V~58.4V |
| Inverter Operating Voltage Range (Single Phase) | 200V-240V |
| Inverter Operating Voltage Range (Three Phase) | 340V-600V |
| Communication | |
| Display | SOC Status Indication, LED Indicator Screen |
| Protocol | RS485/RS232/ CAN (For parallel systems only) |
| General Parameters | |
| Dimensions of Battery Module (Width x Height x Thickness) | |
| Weight (Including tools such as bracket tools) | |
| Installation | Floor (No more than 5 stacks per group) |
| Working Temperature | -20C～+55C |
| Maximum Working Altitude | 4000 m(Derating above 2000 m) |
| nstallation Environment | Outdoor/ Indoor('Please refer to the user manual for installation conditions) |
| Working Relative Humidity | 5%~95% |
| Cooling Mode | Natural Convection |
| Protection Grade | IP 54 |
| Cell | Lithium Iron Phosphate (LFP) |
| Expansibility | A maximum of 16 modules can be used in parallel |
| Matching Inverter | Most current mainstream inverters (lithium) |
| Satisfied criteria | |
| Certificates | CE, CEC,IEC62619,IEC 60730,UN38.3 |
| *1 Test conditions: Based on the manufacturing date, 0.2C charge and discharge rate at 100% depth of discharge (DOD) at 25°C. | |
| *2 The weight of the battery module is subject to the actual object, and a tolerance of±3% is allowed. | |
| *3 The installation of the battery pack is related to product quality assurance as well as safe and stable operation. Please follow the requirements of the user manual for standard installation, use and routine maintenance. | |
